Radiant ceiling profiles Cross®
Design and technology simply connected
Quick. Light. Reliable. Easy. Beautiful. Comfortable. Clean. The next generation of radiant ceiling profiles is here! The new radiant ceiling profiles Cross made of corrosion-resistant aluminium let you experience a comfortable room temperature that can be aesthetically integrated into a wide variety of room situations. The revolutionary, internally developed connection technology enables easy and quick installation.
Benefits
- Simple modular system for numerous versions
- Heating and cooling
- Universal design from industrial to classy
- Quick installation and quick delivery
Impressions
Top product for the user
- Optimum comfort thanks to the natural principle of thermal radiation
- Silent and without dust dispersion – ideally suited for sensitive areas
Top product for the architect
- Adapts perfectly to any room design in terms of design and colour selection
- Can be painted in any colour
- Sleek and slimline or flat
- Optimum use of space by keeping walls and floor free
Top product for the specialist planner
- Available in 3, 4, 5 and 6 m length versions
- Additional installation versions with 2-piece and 3-piece cascades for even more power
- Precise power adjustment to the heating and cooling requirements of the building
- Sophisticated overall system including fixing, connection technology and control
- Equally suitable for new builds and refurbishments
- Suitable for all building types
Top product for the tradesman
- Self-explanatory, ready-to-install accessory components
- Simple assembly by hand without special tools
- No additional sealing material required thanks to the revolutionary connection technology
- All connecting components are made of stainless steel
- Ready-to-install modules from stock
Other benefits
Further products
Radiant ceiling profiles Cross Y17A
Version A (Profile tip pointing upwards)
- Width x height: 173 x 104 mm
- Standard lengths: 3 m, 4 m, 5 m and 6 m
- Strip lengths: 3–100 m
Radiant ceiling profiles Cross Y17V
Version V (Profile tip pointing downwards)
- Width x height: 173 x 104 mm
- Standard lengths: 3 m, 4 m, 5 m and 6 m
- Strip lengths: 3–100 m
Radiant ceiling profiles Cross Y17x2A
Version A (Profile tip pointing upwards)
- Width x height: 365 x 104 mm
- Standard lengths: 3 m, 4 m, 5 m and 6 m
- Strip lengths: 3–100 m
Radiant ceiling profiles Cross Y17x2V
Version V (Profile tip pointing downwards)
- Width x height: 365 x 104 mm
- Standard lengths: 3 m, 4 m, 5 m and 6 m
- Strip lengths: 3–100 m
Radiant ceiling profiles Cross Y17x3A
Version A (Profile tip pointing upwards)
- Width x height: 557 x 104 mm
- Standard lengths: 3 m, 4 m, 5 m and 6 m
- Strip lengths: 3–100 m
Radiant ceiling profiles Cross Y17x3V
Version V (Profile tip pointing downwards)
- Width x height: 557 x 104 mm
- Standard lengths: 3 m, 4 m, 5 m and 6 m
- Strip lengths: 3–100 m
